Purified Water Filling Line For PET Bottles PLC Control SUS 304 Energy Saving

Large Image : Purified Water Filling Line For PET Bottles PLC Control SUS 304 Energy Saving

Product Details:

Place of Origin:	Zhangjiagang, Jiangsu, China
Brand Name:	Reliable
Certification:	CE,TUV,SGS,ISO
Model Number:	CGF

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	USD 40000-45000/SET
Packaging Details:	Wooden package
Delivery Time:	30days
Payment Terms:	Irrevocable letter of credit or T/T
Supply Ability:	15sets a month

Contact Now

Detailed Product Description

Function:	Bottle Water Production Line	Bottle Size:	0.3-2.0L
Suitable Bottle:	PET Bottle	Material:	Food Stage Ss304
Capacity:	2000bph	Color:	Silver Gray
Highlight:	Water Production Line , bottling filling machine

Purified Water Filling Line For PET Bottles PLC Control SUS 304 Energy Saving

Quick Details

Model	Reliable Brand CGF series
Material	Stainless steel 304 food stage , long life time and high quality.
Usage	For Filling Kinds of Non carbonated water , such as still water, mineral water ,flavored water ,spring water ,purified water etc.
Capacity	Based on 500ml bottles, it can produce about 2000~22000bottles per hour.
Bottle size	0.3~2.0L PET Bottles.
Processing	Raw pure water→ raw water tank→ raw water booster pump→mechanical filter→activated carbon filter→precise filter →UF/RO Components→pure water tank (→Ozone device/UV device) →Pure water → Bottle filling machine(lamp checking+bottle dryer)→ Code printer → Bottle labeling machine →Bottle packing machine → Bottle blow molding machine
Main part brand	Mitsubishi, OMRON, SIEMENS .

Technical Parameters

Model	CGF8-8-3	CGF16-12-6	CGF18-18-6	CGF24-24-8	CGF32-32-10
Rinsing Head No	8	16	18	24	32
Filling Head No	8	12	18	24	32
Capping Head No	3	6	6	8	10
RatedCapacity (500ml)	2000BPH	4000BPH	7000-8000BPH	10000-12000BPH	12000-15000BPH
Weight	1.5T	2.2T	3.0T	4.0T	8.0T
Power(KW)	3.0kw	3.5kw	4.0kw	4.8kw	7.6kw
Rated Voltage	380V	380V	380V	380V	380V

Description

1)About the water treatment machine:

Raw water tank to prevent the shortage of the raw water and unsteady pressure. It has the floater ball valve and liquid level sensor.
Raw water tank to guaratee the water supply and steady pressure

2)Pre-treatment:

the mechanical filter to remove the big particle, suspended matter, sediment.
the activated carbon filter to get rid of the odour, organic substance, organic substance, residual chlorine etc.
the precise filter to filter the particles from the pre-treatment part.
UF system: filter particles and colloid in the mineral water and retain mineral element.
the Ozone which makes pure water fresh and UV which sterilizer the bacteria and finally flow the pure water tank.

3)About the bottle filling machine: (optional item:Lamp-checking and bottle dryer)

(takes bottles from the blow molding machine to the air conveyor)
Firstly, washing the bottles. Secondly, filling water into the bottles. Lastly capping the bottles.
Lamp-checking to watch wherther it has the impurity.
Bottle dryer to get rid of the droplet on the bottle.

Pitures Show

Purified Water Filling Line For PET Bottles PLC Control SUS 304 Energy Saving 0

Company Introduction

Brief Introduction	Zhangjiagang Reliable Machinery Co., Ltd.Is a hi-tech designing and manufacturing enterprise, which is specialized in beverage production and packing complete lines as well as various water treatment machines.We are one of the earliest companies engaged in manufacturing liquid filling and packing equipment in China
Main Products	Liquid filling machines (water, fruit juice/tea, carbonated drink, oil, alcohol, plant protein drink, etc.), Barreled filling line (3-5 gallon) Water treatment machines, Labeling & packing machines, semi-automatic /full automatic bottle blowing machines, and injection molding machines.
Good Service	we also supply technique consultation, factory construction design plan, equipment installation and adjustment, technology training and other after-sales services.Now our products are exported to over ten countries and regions, including Southeast Asia, Russia, the Commonwealth of the Independent States, Western Asia and South Africa.
Payment	100%L/C at sight or T/T are both acceptable
Delivery Time	It is based on what kind of products you ordered, but usually it will take about 30 days after receiving your down payment and smaple bottles with caps.

Our Service

1	Your inquiry related to our product & price will be replied within 24hours
2	Well-trained & experienced staff are to answer all your inquiries in English and Chinese
3	Working time: 8:30am ~6:00pm, Monday to Friday(UTC+8).
4	OEM & ODM projects are both available
5	Your business relationship with us will be confidential to any third party.
6	Good after-sale service offered, please get back to us if you got any questions.
